Retractable Faucet Technology Realization Elements

ClassificationFaucet Guide 3340

(1) Technical issues addressed

The wowow faucet offers an easy-to-use retractable faucet that solves the problem of existing faucets that are mostly fixed directly in their designated positions. The leak length of the faucet is not retractable, making it impossible to adjust the faucet according to the actual use. Adjusting the leaky length of the faucet brings inconvenience to people’s use.

(2) Technical solution

In order to achieve the above purpose, wowfaucet adopts a technical solution. An easy-to-use telescopic faucet including a mounting base, the right side of the mounting base is fixedly connected to the left end of the fixed tube, the outer surface of the fixed tube is provided with a sleeve A sliding sleeve is provided, the sliding sleeve is fixedly connected to the left side of the moving tube, the fixed tube is located in the moving tube, the right end of the fixed tube is fixedly connected to the left side of the limit plate, the height of the limit plate is the same as the diameter of the inner wall of the moving tube. The lower surface of the limit plate is fixedly connected to the upper surface of the slider, and the slider is slidingly connected in the slide slot opened on the lower surface of the inner wall of the moving tube, and a water pipe is placed in the fixed tube The left end of the delivery tube is connected to the right side of the mounting base, and the right end of the delivery tube is connected to the left end of the connector through the first through hole opened on the left side of the limit plate.

The right end of the connector is fixedly connected with the right side of the mobile pipe, and the right end of the connector is connected with the left end of the outlet pipe, and the bottom end of the outlet pipe is screwed with a threaded cap, and the bottom surface of the threaded cap is opened with a third hole, and the inner wall of the third hole is fixedly connected with a strainer, and the upper surface of the outlet pipe is equipped with a water control device.

The upper surface of the mobile pipe is opened with a second hole, and a support bar is placed in the second hole, and the bottom of the support bar is fixedly connected with the upper surface of the fixed device, and the lower surface of the fixed device coincides with the upper surface of the fixed pipe. And the upper surface of the support bar passes through the second through hole and is fixedly connected to the lower surface of the pulling device, and the outer surface of the support bar is covered with a spring, and the upper end of the spring is fixedly connected to the lower surface of the pulling device, and the lower surface of the spring is fixedly connected to the upper surface of the mobile tube.

Preferably, the fixing device comprises a fixing plate, the upper surface of the fixing plate being fixedly connected to the bottom end of the support bar, the lower surface of the fixing plate being fixedly connected to the upper surface of the first rubber mat, and the lower surface overlapping with the upper surface of the fixing tube.

Preferably, the pulling apparatus comprises a push-pull handle, the lower surface of the push-pull handle being fixedly connected to the upper end of the support bar, and the outer surface of the push-pull handle being fixedly connected to the second rubber gasket.

Preferably, the water control device comprises a valve, the valve being provided on the upper surface of the outlet pipe, and a handle being provided on the right side of the valve.

Preferably, the shape of the fixing plate and the first rubber mat are both semicircular and the inner wall diameter of the first rubber mat is the same as the diameter of the fixing pipe.

Preferably, the water delivery pipe is of plastic material and the water delivery pipe is freely expandable.
